RK100-01 Metallic Wind Speed Sensor (0-5V)

The RK100-01 Wind speed sensor is specifically designed to accurately and reliably measure wind velocity under the adverse environmental conditions. Digital circuits capable of strong RFI & EMI resistance and automatic temperature compensation are build-in, it output voltage and current signals by electromagnetic induction, The value and horizontal wind speed are linear relation.The Shell is made of high-strength aluminum alloy, the wind cup is made of 304 stainless steel, the PCB board is painted with anti-corrosion coating, featured with water proof, corrosion resisting. Inside and turning position have sealing rings with nice sealing function, stop water, salt fog and dust getting in.Features: – Low starting threshold- Massive all-metal construction- Strong corrosion resistant ability- Stainless steel Wind cup, anti-wind load until 70m/s- Double bearing design- Surge protection design- Easy Installation

Specifications

– Range: 0-30 m/s, 0-60 m/s- Accuracy: +/- 0.5m/s(<5m/s); +/- 3%FS(?5m/s)- Supply voltage: 12-24VDC- Load capacity: >2 kilo ohm- Staring Threshold: <0.5m/s- Limit Wind Speed: 70m/s- Ingress Protection: IP65- Operating Temperature: -30 C to +70 C- Weight(unpacked): 240g- Dimension: Cup rotor: 200 mm, Height: 150 mm- Main material: Cup: 304 stainless steel, Main Body: Aluminum alloy- Finish: Polyester powder electrostatic spraying(black)- Storage Condition: 10 C to 60 C at 20%-90%RH
